Model Number: EE15120A-R1
DC Electronic Load
Volts:	0-50
Current:	0-20
Watt:	150

The EE15120B DC Electronic Load /  Works @ 0.0 Volts Input & real time I/O control
 attach the electronic load block to a heat- sink and your up and running.
used them with D to A's, A to D's, Pots, PLC's to control the current
 These Electronic Loads can be used for both Discharge & Charging Batteries & Devices
The electronic load can act as a Current Regulator for charging

• Specifications
  • Voltage Range  ~50mV - 50 VDC
  • Current Range 0 - 20 Amps Input (drift less than 0.25% at a stable temperature)
    (Full Current 1.0 + Volts at brass input terminals)
    (Current ~50mV - 1.0 Volt ON-resistance dependent of electronic Load / see graph)
  • Reverse Current Protection 50 Amp
  • ON-Resistance Max. 0.05 Ohms (Typical)
  • Input Capacitance less than 5,000 pF
  • Input Inductance less than 100 nH
  • Current Control real time control
  • Current Control Adjustable or Fixed (Resistors / Pots / D to As)
  • Current Control || Internal / External
  • Current Control (Voltage Input)
  • Constant Current 0-4.0 Vdc  for Full Scale = 0-20 Amps
  • Current Monitor (Voltage Output) 0-4.0 Vdc 10mA max. Full Scale = 0-20 Amps
  • Voltage Monitor (Voltage Output) 0-5.0 Vdc 10mA max. Full Scale = 0-50 Volts
  • Power Dissipation 125 Watts Max.  with High Temperature Heat Sink @ 50C
  • Power Modes | Constant Current (CC) | Qusi-Constant Power (QCP) | Standard Operation
  • Power Modes | Constant Resistance & Constant Power ( Requires Computer Control)
  • Qusi-Power Mode = Startup in Resistance mode & Switched to Qusi-Constant Power
  • Adjustable Startup Voltage / Slew Rate / Startup Voltage Selectable, Internal / External
  • Power Input Bias External (+12VDC @ 150 ma regulated) or ( 18-30 volts Unregulated )
• LED bias power light indicator
• Automatic Power Limiter Circuit / Some restrictions apply see full specifications
• Over Temperature 87-95C (typical) || Optional adjustable setting or fixed setting
• Transient & Over-Voltage Protection (58.1+ Volts)
• Slew Rate Max. typical 6 Amps / uS ( External Pulse) || Default is 0.5A/uS
• Frequency Range typical / DC - 1.0 Khz full power / 3db @ 8Khz / 6db @ 20.0 Khz
• Drift less than 0.003 mV / Deg. C (Current Monitor)
• Offset less than 0.03 mV at any temperature (Current Monitor)
• Stability @ 25 Deg C 10 Min. Current +/- 0.010 Amps
• Stability @ 25 Deg C 24 Hrs. Current +/- 0.075 Amps any load
• Humidity 100 % @ 25 Deg C 24 Hrs. Absorption 0.3%
• Enclosure Anti-Static / Thermal Epoxy

• Temperature Range -25 deg C to +85deg C (Internal Electronics)

• Absolute Maximum Temperature Range -25 deg C to +70deg C (Conduction Plate)

• Size L 4.91" x W 3.0" x H 1.75"
• Weight 17.5 Oz.
• Warranty 2 years under normal use some restrictions apply
• Electronic Load Low Voltage Operation
  • Graph of low voltage electronic load operation (PDF)
  • Graph of Voltage electronic load Operation
